The RTR-4 system is designed to help law enforcement, military, customs and security personnel search for explosives, weapons, narcotics and other contraband. The system can reveal the contents of parcels, baggage, boxes and crates, vehicle tires and body panels, aircraft walls and wings, building walls, and many other targets.
The RTR-4 digital x-ray system lets you look inside, quickly and safely. The system is designed to help law enforcement, military, customs and security personnel search for explosives, weapons, narcotics and other contraband. The system can reveal the contents of parcels, baggage, boxes and crates, vehicle tires and body panels, aircraft walls and wings, building walls, and many other targets.

Features:
* The RTR-4 system consists of a lightweight, compact x-ray source and imaging unit that are positioned on opposite sides of the target object, plus a standard notebook computer for controlling the system and analyzing images. The control computer is connected to the imager by an Ethernet cable or optional wireless connection. (You will receive the wired option.)
* The system is fully digital for fast viewing, no image degradation, and easy image analysis and management — far superior to film and analog systems.
* The RTR-4 system is designed for a use in a wide range of field scenarios. The system can be used in tight quarters, right down to ground level. With a total weight of just 12 kg (26 lbs), the x-ray source and imager are easy to move into position by hand, and can be mounted on bomb-disposal robots for remote operation.

The standard RTR-4 system includes the following components:
* X-ray source: The standard source can penetrate more than 25mm (1 inch) of steel. A more powerful source is also available.
* Imager: The standard imaging unit provides high-resolution images up to 20 x 25cm (8 x 10 in).
* Control computer: A standard notebook computer provides system control and image-analysis functions.The computer is supplied with our RTR-4 database and image-analysis software..
* The RTR-4 software provides a variety of features to bring out items of interest in x-ray images, including zoom, pseudo-color, contrast stretch, edge detection and sharpening, smoothing, embossing, and histogram equalization. These features can be applied to the entire image or to a specific region of interest. The system also provides multi-image display, grid overlay, point-to-point distance measurement, and annotation.
* Images are stored as standard TIFF files in the system database. Video, audio, text and other data can be stored along with each image. Individual images and accompanying data can easily be extracted from the database for emailing or other uses.

Included:
1x SAIC RTR-4 X-Ray Controller PC – Dell Laptop w/ battery, charger, and Imager Interface LAN Card
1x SAIC RTR-4 X-Ray Imager
1x Imager-PC Data Connection Cable
2x Imager Batteries and Charging Station
1x Golden Engineering XR200 X-Ray Source w/ key
1x Imager-X-Ray Trigger/Fire Connection Cable
2x batteries, and Charging Station
1x SAIC RTR-4 Re-installation and Manual CD
