Artec Space Spider 3D Scanner
Artec Space Spider is a 3D scanner with high resolution, high accuracy and ability to see sharp edges. Such features make Artec Spider the perfect solution for mass production and industrial design where higher-precision scanning of objects with sharp edges and intricate details is required.
Artec Space Spider Specifications
| Scanner Type | Handheld | |
|---|---|---|
| 3D Point Accuracy | Up to 0.050 mm (0.002 in) |
|
| 3D Resolution | Up to 0.10 mm (Up to 0.004 in) |
|
| 3D Accuracy Over Distance | Up to 0.05 mm + 0.3 mm/m (Up to 0.002 in + .0036 in/ft) |
|
| Hybrid Geometry and Texture Tracking | Yes | |
| Data Processing Algorithms | Geometry and texture based | |
| Working Distance | 0.2 – 0.3 m (0.6 – 1 ft) |
|
| Volume Capture Zone | 2,000 cm³ (122 in³) |
|
| Linear Field of View, H × W @ Closest Range |
90 × 70 mm (3.5 × 2.8 in) |
|
| Linear Field of View, H × W @ Furthest Range |
180 × 140 mm (7 × 5.5 in) |
|
| Angular Field of View, H × W | 30 × 21° | |
| Ability to Capture Texture | Yes | |
| Teture Resolution | 1.3 mp | |
| Colors | 24 bpp | |
| 3D Reconstruction Rate for Real Time Fusion | Up to 7.5 fps | |
| 3D Reconstruction Rate for Video Recording | Up to 7.5 fps | |
| Data Acquisition Speed | 1 mln points/s | |
| 3D Exposure Time | 0.0002 s | |
| 2D Exposure Time | 0.0002 s | |
| 3D Light Source | Blue LED | |
| 2D Light Source | White 6 LED array | |
| Display / Touchscreen | USB streaming through external computer | |
| Multi-core Processing | On external computer | |
| Interface | 1 × USB 2.0, USB 3.0 compatible | |
