Olympus Panametrics Epoch LTC Handheld Ultrasonic Flaw Detector w/ AWS

Olympus Panametrics Epoch LTC Handheld Ultrasonic Flaw Detector w/ AWS
The EPocH ltc digital ultrasonic flaw detector offers state-of-the-art technology in a compact and lightweight package. Based on the class-leading EPocH Xt, the EPocH ltc is full featured, complies with the En 12668-1 standard, and has various specialized options to meet your inspection needs.

Ultrasonic flaw detection is widely used in locating and sizing hidden cracks, voids, disbonds, and similar discontinuities in welds, forgings, billets, axles, shafts, tanks and pressure vessels, turbines, and structural components.

Features:
– Designed for IP67 rating to ensure field ruggedness
– Complies with the EN12668-1 standard
– Only 960 g (2.1 lb)
– Full-color VGA display with transflective technology
– USB On-The-Go port for computer communication and direct printing
– Onboard and miniSD Card storage capabilities for the data logger
– Standard dynamic DAC/TVG
– Standard onboard DGS/AVG
– Digital high dynamic range receiver with digital filters
– High-performance square wave pulser with tuning option

Specifications:
– Dimensions (W x H x D): 128.9 mm x 223.3 mm x 55.1 mm (5.07 in. x 8.79 in. x 2.17 in.)
– Weight: 960 g (2.12 lb) with li-ion battery
– Keypad: English
– Display languages: English, spanish, French, German, italian, Japanese, chinese, russian, norwegian, Swedish
– Transducer connection: lEMo 00
– Battery: rechargeable lithium-ion. standard aa battery tray
– Battery operating time: lithium-ion rechargeable battery: 8 hours; aa li-Fes2: 6 hours aa niMH cells: 4 hours; aa alkaline cells: 3 hours
– Power compatibility: 100/120 Vac, 200/240 Vac, 50-60 Hz
– Display type: color transflective lcD, refresh rate of 60 Hz, user-selectable color schemes and brightness, two split-screen modes and one full-screen mode
– Display dimensions (W x H): 640 pixels x 480 pixels, 75 mm x 56 mm (2.95 in. x 2.21 in.), 94 mm (3.7 in.) diagonal
– Pulser: Fixed width square wave pulser optimized for general flaw detection applications
– Pulse width: Fixed width in base instrument. adjustable from 45 ns to 5,000 ns (0.1 MHz) with EPltc-sWP option
– Energy settings: 100 V to 400 V in 100 V increments
– Damping: 50 Ω, 100 Ω, 200 Ω, 400 Ω

Includes:
– Olympus Epoch LTC Handheld Ultrasonic Flaw Detector Installed Option(s): AWS
– AC Adapter/Charger
– Power Cord
– SUB PC Interface Cable
– User Manual On CD-ROM
– Carrying Case
